Water-based Elastomeric Decorative Coating (EN1504-2)

Overview

Protective concrete coatingsMonodex Smooth is a high performance water based, elastomeric, high build, decorative coating which provides protection against carbonation and water ingress, yet allows damp substrates to breathe. It is ultra-fast drying which enables two coat applications to take place on the same day and facilitates year round usage. Monodex Smooth resists the growth of mould and fungi and is ideal both for new construction and refurbishment projects.

Monodex Smooth is a single component, high build, decorative, waterproof coating based on an advanced micropolymer resin binder which cross-links to give outstanding durability over a service life up to 15 years. The elastomeric nature facilitates substrate movement and bridging of hairline cracks.

Monodex Smooth can be reinforced to accommodate higher levels of substrate movement. It protects reinforced concrete structures from carbonation and allows substrate moisture to escape without blistering or weakening of adhesion. Monodex Smooth is available in a range of attractive colours (see Flexcrete Coatings Colour Chart).

Monodex Smooth can be applied using Graco Pumps (see the  Airless Spraying of Decorative Protective Coatings & Membranes Graco Pumps).

Service Life Up to 15 YearsAdvantages

  • High diffusion resistance to carbon dioxide, offering complete protection from the effects of carbonation
  • Active encapsulated in-film biocide inhibits the growth of mould, mildew and lichens
  • Advanced cross-linking micropolymer resin system forms a durable coating with excellent adhesion
  • Fast drying allowing two coat applications on the same day and year round use
  • Ultra Fast Drying FormulationLow hazard, water based product with no flash point. Equipment easily cleaned with water
  • Low water vapour diffusion resistance allows damp substrates to breathe and dry out without blistering
  • High colour pigment concentration obliterates strong underlying colours to produce an attractive matt finish
  • Easily reinforced locally over cracks and joints, or overall to effectively seal crazed surfaces.

ComplianceSustainable Coatings

CE marked in accordance with BS EN 1504 Part 2.

Specification Clause

The anti-carbonation coating shall be a single component, high build, waterproof coating incorporating a micropolymer, cross-linking resin binder. It shall be CE marked in accordance with BS EN 1504-2 and shall comply with the following performance specification:

  • Permeability to Carbon Dioxide no greater than 2.94 x 10-7 cm2/s in accordance with EN 1062-6 (equivalent concrete thickness of 300mm and equivalent air layer thickness 121m at 239μm dry film thickness)
  • No blistering, cracking or flaking after at least 20,000 hours QUV-B weathering in accordance with EN 1062-11
  • Water vapour transmission no greater than 46g/m²/day in accordance with BS EN ISO 7783-2.

Contact Us >>

Uses Application Method Application Thickness Performance Pack Yield

High build, decorative anti-carbonation coating, which allows damp substrates to breathe. 15 year system.

  • Airless spray application
  • Brush
  • Roller
  • 1st Coat 200μm
  • 2nd Coat 200μm
  • Overall DFT=240μm
  • Elongation = 279%
  • Water Vapour: SD=0.48m, SC=300mm
  • Euroclass B-s1,d0
  • 0.2 litres/m²/coat
  • 5m²/litre/coat
  • 15 litres covers 37.5m²
